Place of Origin:
Guangdong, China
Brand Name:
e-mingze
Certification:
CE,ROHS,TUV,LVD
Model Number:
MZ-076
Document:
Product description
The Wall Mounted EV Charger is designed for reliable and intelligent electric vehicle charging. Featuring a Type 2 connector, 32A charging current, WiFi APP control, and RFID authentication, it provides a convenient charging solution for both residential and commercial applications.
| Specifications | |
|---|---|
| Execution standard: | Type2 |
| Rated voltage: | AC 220V/380V |
| Output current: | 8A-32A adjustable (color screen model) |
| Class protection: | IP66(control box),IP55(head - coupling state) |
| Input frequency: | 50/60Hz |
| Output power: | 7-22KW |
| Operating temperature: | -30°C~+50 °C |
| Display mode: | LED3.5-inch screen |
| Starting method: | Plug and play (touch the button, can reserve charging, can manually adjust the current) |
| Cable length: | 5/10/15/20 meters, customizable |
| Leakage protection type: |
leakage protection, over-current protection, over-voltage protection, under-voltage protection, plug end and over-temperature protection in the box |
| Input plug: | 3 wires/5 wires |
| Installation method: | Wall mounted /Floor mounted |
| Net weight: | 4.8KG |
| GW: | 5KG |
| Warranty: | 12 months |
| Package size: |
Small carry case: 50*35*23cm 1pc/carton Large carry case: 51*38*48cm 4pcs/carton One large carry case can hold two small carry cases |
| Product material: | high flame retardant plastic, flame retardant grade UL94V-0 |
| Product function: |
1. Card swiping for charging to prevent unauthorized charging. 2. Can schedule charging, record charging time and electricity consumption. 3. Supports charging most electric and hybrid vehicles on the market. 4. High quality pure copper COC certiied cable. 5. Adjustable current 6. Supports vehicle charging lock function. 7.Automatic stop when fully charged. 8. Intelligent screen display to keep track of charging status at all times |
Deliver up to 7kW, 11kW, or 22kW charging power with stable and efficient energy transfer, reducing charging time for electric vehicles at home or commercial locations.
Monitor charging status, adjust charging current, schedule charging sessions, track energy consumption, and manage charging remotely through the mobile APP.
Support RFID authentication to prevent unauthorized use, making it ideal for apartments, offices, public parking lots, and shared charging environments.
Compatible with most European electric vehicles and plug-in hybrid vehicles equipped with a Type 2 charging port.
Set charging schedules during off-peak electricity hours to reduce energy costs and optimize charging efficiency.
Built-in protection against overcurrent, overvoltage, undervoltage, leakage, overheating, short circuit, and surge conditions for safe daily charging.
